Digital Signage Display
5501-C
55” TFT LCD, 4000 nits LED Backlight, 1920x1080
- High Brightness 4000 nits
- Sunlight Readable
- RGBW Optical Color Technology
- Wide Viewing Angle of 178°(H), 178°(V)
- LED Backlight
- Low Power Consumption
- LCD Blackening Defect Free (H-Tni 105℃)
- BL MTBF: 100,000 hours
| Model Name | DLF5501-C | DLH5501-C | DLD5501-C |
| Description | 55” TFT LCD, 4000nits LED Backlight, 1920x1080 | ||
| size | 55" | ||
| Display area (mm) | 1209.6(H) x 680.4(V) | ||
| Brightness | 4000 cd/m² | ||
| Resolution | 1920x1080 | ||
| Aspect ratio | 16:9 | ||
| Contrast ratio | 1300:1 | ||
| Pixel pitch (mm) | 0.63(H) x 0.63 (V) | ||
| Pixel per inch (PPI) | 40 | ||
| Viewing angle | 178° (H), 178° (V) | ||
| Color saturation (NTSC) | 80% | ||
| Display colors | 1.07G | ||
| Response time (Typical) | 8ms | ||
| Panel interface | LVDS | ||
| Input interface | HDMI, DP | ||
| Input power | AC100~240V | ||
| Power consumption | 229W | 232W | |
| Dimensions (mm) | 1236.5(W) x 707.5(H) x 56.14(D) | 1240.1(W) x 711.1(H) x 107.5(D) | |
| Bezel size (U/B/L/R) | 13.551/13.551/13.45/13.45 mm | 15.35/15.35/15.25/15.25 mm | |
| Weight (Net) | 18.5 kg | 26.3 kg | |
| Mounting | 400x200,400x300mm | ||
| OSD key | 4 Keys (Power Switch, Menu, +, -,Exit) | ||
| OSD control | Brightness, Color, Contrast, Auto Turing, H/V Position…etc | ||
| Operating temperature | -20 ˚C ~ 60 ˚C | ||
| Storage temperature | -30 ˚C ~ 80 ˚C | ||
