Heim / Produkte / Industrial Display / Ubipixel™-Industrial High Brightness LCDs / 1015-M

industrial grade sunlight readable LCD

1015-M

10.1” TFT LCD, 1000nits LED Backlight, 1920x1200
  • High Brightness 1000 nits
  • Sunlight Readable
  • LED Backlight
  • Low Power Consumption
  • Wide Temperature(-20 ˚C ~ 70 ˚C)
  • BL MTBF: 50,000 hours
DRUCKEN
Anfrage Vergleich

Hauptmerkmale

  • Transportation

  • Sunlight Readable

  • Low Power Consumption

  • Kiosk

  • Gaming

  • Automation

  • Wide Temp

INTRODUCTION Spezifikationen Download
The 1015-M is a 10.1 inch industrial grade sunlight readable LCD, with high brightness 1000 nits, it produce sharp images, crisp text and lifelike colors. The Ubipixel LED backlight technology ensures high reliability and low power consumption, suitable for outdoor application, kiosk, factory automation, military, and transportation application.
Model Name ULF1015-M ULH1015-M ULO1015-M
Description 10.1” TFT LCD, 1000 nits LED Backlight, 1920x1200
Size 10.1”
Display area (mm) 216.8(H) x 135.5(V)
Brightness 1000 cd/m²
Resolution 1920x1200
Aspect ratio 16 : 10
Contrast ratio 1000 :1
Pixel pitch (mm) 0.11292(H) x 0.11292(V)
Pixel per inch (PPI) 224
Viewing angle 170°(H),170°(V)
Color saturation (NTSC) 83%
Display colors 16.7M
Response time (Typical) 25ms
Video interface LVDS
Input interface HDMI,DP
Input power DC 12V
Power consumption 6.5W 8.5W
Dimensions (mm) 229.46 x 149.10 x 8.0 245.8 x 164.4 x 51.1
Bezel size (U/B/L/R) 4.35/9.25/5.04/7.62 mm 14.5/14.5/14.5/14.5 mm
Weight (Net) 0.8 kg 1.3 kg
Mounting   75x75 mm
OSD key 4 Keys (Power Switch, Menu, +, -)
OSD control Brightness, Color, Contrast, Auto Turing, H/V Position…etc
Operating temperature -20 ˚C ~ 70 ˚C
Storage temperature -30 ˚C ~ 80 ˚C
