Wide Temperature

Operating temperature normally means the temperature at which an electrical or mechanical device operates. The device would operate effectively within a specified temperature range which may vary depending on the device functionality and the application context, and then range from the the minimum operating temperature to the maximum operating temperature (or the peak operating temperature). Outside this range of safe operating temperatures the device may fail. Industrial devices generally operate over a broader temperature range than commercial-grade devices.


Normal operating temperature ranges are affected by several factors, such as the power dissipation of the device. These factors are used to define a "threshold temperature" of a device, which means the maximum normal operating temperature, and the maximum operating temperature beyond which the device will no longer be able to perform as effectively as it would otherwise. Between these two temperatures, the device will operate at a non-peak level. For instance, a resistor may have a threshold temperature of 70°C and a maximum temperature of 155°C, between which it exhibits a thermal derating.

The extent of the operating temperature also translates into reliability engineering. To overcome demanding temperature environments, Litemax offers industrial solutions with Wide Temperature from T1 to T3: T1: -20°C~+70°C / T2: -40°C~+70°C / T3: -40°C~+85°C


Ranges from T1 to T3 help put system designers and customers at ease that any “Made by Litemax” device is suitable for its designated vertical application, and will withstand the environmental conditions in which it is utilized.



Intelligent Thermal Control

Through intelligent thermal management technologies, Litemax is enabling smarter platforms for various vertical markets deploying display systems. Through the intelligent thermal control board, Litemax helps system integrators and engineers around the world improve efficiency and reliability. What does Litemax thermal control board offer? Infographics demonstrate how Litemax optimizes the temperature through the intelligent platform as the display automatically cools down or heats up itself, depending on LCD temperature.



Benefits

  • Intelligent, multi-purpose thermal control board with 8bit MCU processor
  • Wide operation temperature -40°C to 80°C
  • 16 channels of fan control functionality
  • 3 channels of temperature sensors
  • 4 channels of lighting management
  • Can be connected to control different sensors in use
  • 1 channel of I2C and memory program port
  • ROHS & Reach compliant



Daisy Chain

Daisy chain is a wiring scheme in which multiple devices, and in this case, Litemax displays, are wired together in sequence or in a ring. There is a master chain that may come with multiple slave chains. The objective of daisy chains is to broadcast real-time information consistently and simultaneously across various different points within the installation environment. Train stations, airports, department stores, large campuses, sports arenas or stadiums are among many scenarios where daisy chain technology brings great benefits to system integrators and designers. 100M long distance video/ audio transmission via an easy network CAT5 cable is the most cost effective solution for transportation.
