Digital Signage Display

5501-B

55” TFT LCD, 4000nits, LED Backlight, 3840x2160
  • High Brightness 4000 nits
  • Sunlight Readable
  • RGBW Optical Color Technology
  • Wide Viewing Angle of 178°(H), 178°(V)
  • LED Backlight
  • Low Power Consumption
  • LCD Blackening Defect Free (H-Tni 105℃)
  • BL MTBF: 100,000 hours
DRUCKEN
Anfrage Vergleich

Hauptmerkmale

  • Wide Viewing Angle

  • Sunlight Readable

  • MTBF 100K

  • Low Power Consumption

  • Blackening Defect Free

INTRODUCTION Spezifikationen Download
The 5501-B is a 55 inch industrial grade sunlight readable LCD, with high brightness 4000 nits, it produce sharp images, crisp text and lifelike colors. The Durapixel LED backlight technology ensures high reliability and low power consumption, suitable for outdoor application, kiosk, factory automation, military, transportation and gaming application.
Model Name DLF5501-B DLH5501-B DLD5501-B
Description 55” TFT LCD, 4000nits LED Backlight, 3840x2160
size 55"
Display area (mm) 1209.6(H) x 680.4(V)
Brightness 4000 cd/m²
Resolution 3840x2160
Aspect ratio 16:9
Contrast ratio 1400:1
Pixel pitch (mm) 0.315 (H) x 0.315 (V)
Pixel per inch (PPI) 80
Viewing angle 178° (H), 178° (V)
Color saturation (NTSC) 80%
Display colors 1.07G
Response time (Typical) 14ms
Panel interface V-by-One
Input interface HDMI, DP
Input power AC100~240V
Power consumption 255W 258W
Dimensions (mm) 1236.5(W) x 707.5(H) x 58.6(D) 1240.1(W) x 711.1(H) x 107.5(D)
Bezel size (U/B/L/R) 13.55/13.55/13.45/13.45 mm 15.35/15.35/15.25/15.25 mm
Weight (Net) 18.1 kg 27 kg
Mounting   400x200,400x300
OSD key 5 Keys (Power Switch, Menu, +, -,Exit)
OSD control Brightness, Color, Contrast, Auto Turing, H/V Position…etc
Operating temperature -20 ˚C ~ 60 ˚C
Storage temperature -20 ˚C ~ 60 ˚C
