Heim / Produkte / Industrial Computing / Embedded Box PCs / Entry BOX PC / IBOX-SKL2 C TYPE

Entry BOX PC

IBOX-SKL2 C TYPE

Fanless Box system with Intel® Core™ i3-6100U/Celeron® 3955U (Skylake-U) Processor, HDMI/DP, 3 USB, 2 GbE LAN
  • Intel® Core™ i3-6100U/ Celeron® 3955U (Skylake-U) Processor
  • Dual display: HDMI/DP
  • Two Intel Gigabit Ethernet ports
  • 1 HDMI, 1 DP, 3 USB, 3 COM, 2 LAN ,1AUIDO
  • DC 9 ~ 36V input
  • Watchdog timer
DRUCKEN
Anfrage Vergleich

Hauptmerkmale

  • Wide DC-in 9-36V

  • Fanless

Spezifikationen Download
Model name IBOX-SKL2 C TYPE
System
CPU Intel® Core™ i3-6100U 2.3GHz dual core processor(TDP 15W)
Intel® Celeron® 3955U 2.0GHz dual core processor(TDP 15W)
Chipset Intel® SkyLake-U SoC integrated
BIOS AMI SPI Flash ROM
System memory 1 x 204-pin DDR3L 2133MHz SDRAM; max. up to 16GB
Graphic Intel® HD Gen. 9 graphics
Watchdog timer Yes
I/O
USB 2 x USB 3.0, 1 x USB 2.0
COM 3 x COM (1 x RS-232/422/485, 2 x RS-232)
LAN 2
Display 1 x DP, 1 x HDMI
Audio Mic-in, Line-in, Line-out
PS/2 N/A
Others 2 x SMA hole
Storage Support
HDD 1 x 2.5" HDD
M.2 N/A
mSATA 1 (with Mini-PCIe)
Expansion
Mini-PCIe 2 (1 x Full-size w/ SIM; 1 x Full-size w/ mSATA
M.2 N/A
Power
Power supply Wide range DC 9 ~ 36V input, Phoenix connector
Environmental
Operating Temperature 0°C ~ 50°C (Optional -20°C, -40°C)
Storage Temperature -20°C ~ 80°C
Relative Humidity 0% ~ 90% (non-condensing)
Mechanical
Construction Aluminum extrusion and heavy-duty steel
Standard color Silver
Mounting Wall mount / VESA100 /DIN mount (optional)
Weight 1 kg
Dimensions (W)x(D)x(H)mm 178 mm(W) x 123.2 mm(D) x 49.8 mm(H)
