Display Control Board, WUXGA

AD8891GDPH

Display Control Board, WUXGA
  • Max Resolution Up To Full HD
  • Analog RGB Input up to 205MHz
  • ULTRA-RELIABLE DVI-I Input
  • HDMI Input (HDMI1.3)
  • Display Port Input
  • Dual/Single LVDS interface
  • Support Panel DC 3.3V/5V/12V Output
  • OSD Control
  • PWM/DC Dimming Control for Backlight Driver
  • External RS232 Control (Optional)
  • Input Power DC 24V or 12V (Optional)
  • Display Port Input (support display port 1.2a)
  • Audio in and 3Wx2(4Ω)Audio Out (Optional)
  • *External Digital Light Sensor Brightness Control (Optional)
  • *External Light Sensor Brightness Control (Optional)Support Output Voltage 12V(1A) and 5V(1A)
Model name AD8891GDPH
Chipset TSUMP88CDT9-1
Max. Resolution WUXGA (1920X1200)
Interface Single/Dual LVDS
Input Power DC 12V/24V (Optional)
Panel Power Selection 3.3V, 5V,12V
Video Input (Standard) DVI-I, HDMI, Display Port
RS232 Control Port Yes (Optional)
Light Sensor Yes (Optional)
Speaker 3W x2
External VR Control Yes (Optional)
IR Yes (Optional)
Dimension 150 x 100 mm
F / R Control Button 4 Key
4 key Power Switch, Menu, Select (+,-)
OSD Menu Brightness, Color, Contrast, Auto Turing, H/V Position…etc
Pixel Color 8 bits(LVDS)
Inputs DVI-I, HDMI, Display Port
Resolution 1920X1200
