TFT-LCD display

2955-I

29.5” Resizing LCD,1000 nits LED backlight, 2160 x 2160 Square aspect ratio 1:1
  • Resizing LCD
  • Square Screen (1 : 1)
  • High Brightness 1000 nits
  • Sunlight Readable
  • LED Backlight
  • Slim Bezel
  • BL MTBF: 100,000 hours

主要特色

  • Transportation

  • Sunlight Readable

  • Digital Signage

Model Name SSD2955-I SSF/SSH2955-I
Description 29.5” Resizing LCD, 1000 nits LED backlight, 2160x2160
size 29.5”
Display area (mm) 529.4(H) x 529.4(V)  529.416(H) x 529.416(V)
Brightness 1000 cd/m²
Resolution 2160x2160
Aspect ratio 1 : 1
Contrast ratio 5800 : 1
Pixel pitch (mm) 0.2451(H) x 0.2451(V)
Pixel per inch (PPI) 104
Viewing angle 178°(H),178°(V)
Color saturation (NTSC) 83%
Display colors 1.07G
Response time (Typical) 9.5ms
Panel Interface V-by-One
Video interface HDMI, DP
Input power DC 12V
Power consumption 76W 74W (with AD board 76W)
Dimensions (mm) 564.5 x 564.5 x 61.4 562 x 562 x 23.4
Bezel size (U/B/L/R) 17.5/17.5/17.5/17.5 mm 16.292/16.292/16.292/16.292
Weight (Net) 9.6kg 4.8kg
Mounting 100x100, 200x200
OSD key 5 Keys (Power Switch, Menu, +, Exit, -)
OSD control Brightness, Color, Contrast, Auto Turing, H/V Position…etc
Operating temperature 0°C ~ +50°C
Storage temperature -20°C ~ +60°C
