Home / Product / Industrial Display / Durapixel™ - Sunlight Readable LCDs / 1968-U 2000nits

Digital Signage Display

1968-U 2000nits

19" TFT LCD, 2000 nits LED backlight, 1280x1024
  • 19" sunlight readable, high brightness (2,000 nits)
  • Resolutions: 1280 x 1024
  • Industry leading LED backlight
  • Aspect ratio of 5:4
  • High contrast ratio (1000:1)
  • Low power consumption
  • BL MTBF: 100,000 hours
PRINT
INQUIRY COMPARE

Main Features

  • Wide Temp

  • Sunlight Readable

  • Low Power Consumption

INTRODUCTION SPECIFICATION Download
The 1968-U 2000nits is a 19 inch industrial grade sunlight readable LCD, with high brightness 2000 nits and high color saturation, it produces sharp images, crisp text and lifelike colors. The Durapixel LED backlight technology ensures high reliability and low power consumption, suitable for outdoor application, kiosk, factory automation, military, transportation and gaming application.
Model Name DLF1968-U DLH1968-U DLD1968-U
Description 19” TFT LCD, 2000 nits LED Backlight, 1280x1024
size 19"
Display area (mm) 376.32(H) x 301.06(V)
Brightness 2000 cd/m²
Resolution 1280x1024
Aspect ratio 5:4
Contrast ratio 1000:1
Pixel pitch (mm) 0.294 (H) x 0.294 (V)
Pixel per inch (PPI) 86
Viewing angle 170° (H), 160° (V)
Color saturation (NTSC) 81%
Display colors 16.7M
Response time (Typical) 10ms
Panel interface LVDS
Input interface VGA, DVI-D, HDMI
Input power DC 12V
Power consumption 36W 39W
Dimensions (mm) 396.0 x 324.0 x 14.5 396.00 x 326.01 x 36.0
Bezel size (U/B/L/R) 11.475/11.475/9.840/9.840 mm 12.47/12.48/9.84/9.84 mm
Weight (Net) 2.4 kg 3 kg
Mounting   75 x 75, 100 x 100 mm
OSD key 4 keys (Power switch, menu, +, -)
OSD control Brightness, Color, Contrast, Auto Turing, H/V Position…etc
Operating temperature -30°C ~ 85°C
Storage temperature -30°C ~ 85°C
