Transparent OLED Display

TLD3000-L

30" Transparent OLED Display
  • Panel Size: 30”
  • Resolution: 1366 x 768
  • Brightness: 150~350nits (Auto Dimming)
  • Self-emissive (w/o Backlight)
  • Thickness: 1.62mm (Ultra-thin)
  • High Contrast Ratio: 135,000 : 1
  • Transparent Ratio: 43%
  • Reflectivity Ratio: 29%
  • Color Depth: 1.07B
  • High Color Saturation: 90%
  • Low Power Consumption
PRINT
INQUIRY COMPARE

Main Features

  • High Performance

  • Transportation

  • Low Power Consumption

  • Gaming

INTRODUCTION SPECIFICATION Download
TLD3000-L is an innovative market-leading transparent OLED display, resolution 1366x768, self-emissive without backlight, high contrast ratio, and high color saturation. It is an innovative, transparent OLED display. it provides transparent OLED panel with specific aspect ratios for digital signage, AI virtual interaction, transparent window, exhibition hall, museums and boutiques.
Model Name TLD3000-L
Description 30” Transparent OLED, 200nits , 1366x768
size 30”
Display area (mm) 664.29(H) x 373.48(V)
Brightness Normal 200 cd/m2 and Peak 600 cd/m2
Resolution 1366x768
Aspect ratio 16:9
Contrast ratio 210000 : 1
Pixel pitch (mm) 0.4863(H) x 0.4863(V)
Pixel per inch (PPI) 52
Viewing angle 120°(H),120°(V)
Color saturation (NTSC) 87%
Display colors 1.07B
Response time (Typical) 8ms
Panel Interface V-by-One
Input Interface HDMI , DP
Input power DC 24V
Power consumption 36W
Dimensions (mm) 702x441.5x180
Bezel size (U/B/L/R) 5.9/62.1/5.9/5.9mm
Weight (Net) 6.87Kg
OSD key 5 Keys (Power Switch, Menu, Select (+,-), Auto)
OSD control Brightness, Color, Contrast, Auto Turing, H/V Position…etc
Operating temperature 0 ˚C ~ 45 ˚C
Storage temperature -20°C ~ 60°C
