Transportation Panel PCs

IPPS-4805-APL9

48" Bar-type Panel PC with Intel® Apollo Lake Atom® SoC
  • Intel@ Apollo Lake Atom@ SoC
  • EN50155
  • 48" LCD, 1920 x 268, 1000 nits
  • High Brightness, Sunlight Readable
  • Auto-Dimming
  • 3mm Glass with Front IP65 Full Flat Design
  • Display Thickness 25mm; 1.5mm Slim Border
  • M12 Connector for LAN, DC 110V input
IMPRIMER
DEMANDE COMPARER

Principales caractéristiques

  • Transportation

  • Traffice Recognition

  • Sunlight Readable

  • Full IP65

INTRODUCTION Spécifications TÉLÉCHARGER
IPPS-4805-APL9 is a fanless Passenger Information System,  serving as a reliable platform to provide passenger information on wide versatility of vehicles, such as trains and trams. It features extra slim and lightly design to fit in cramped space.

Powered by Intel® Atom®/Pentium®/Celeron® (ApolloLake SoC) Processor, and designed from the ground up to be robustness with Front IP (Ingress protection) 65 with full flat design.  It supports sunlight readable with auto dimming  for smoothly implementation in a wide working temperature ranging from -20°C to 50°C, to make sure its best operation in harsh environment and deliver the real-time information to passengers.
Model Name IPPS-4805-APL9
LCD
Display Type 48" Resizing TFT LCD
Aspect Ratio 1200:1
Resolution 1920x268 pixel
Brightness 1000 cd/m²
Color 16.7M Colors
Pixel Pitch (H/V) 0.63 x 0.63mm
Constrast Ratio 1200:1
Viewing Angle (H/V) 178°/178°(typ.)
Backlight MTBF (typ.) 100,000 hrs(typ.)
System
Memory 1 x DDR3L SDRAM;max. up to 8GB
Graphic Intel® HD Gen 9-LP Graphics
Watchdog Timer interval: Programmable 1-255 sec. Output:System reset
Indicators 1 x System indicator
Controls N/A
System I/O
USB 2 x LAN Connector Type:M12 Can add COM, USB Port
Environment
Operating Temperature 0°C-50°C
Storage Temperature -20°C-60°C
