Intel® SDM Ready Display

DLS8500-I

85” TFT LCD, LED Backlight 2000nits, UHD(3840x2160)
  • Large 85" 4K2K professional signage display
  • Support Intel® Smart Display Module (SDM)
  • Plug and play with SDM-L and SDM-S CPU boards
  • High brightness 2000nits immersive technology
  • High color saturation, stunning visual clarity display
  • Long lasting 24/7 operations
  • Stylish, slim and lightweight design.
  • Regular brightness 500 nits available

Main Features

  • 4K

Model name DLS8500-I
Description 85” 2000 nits, 4K2K SDM Solution
Size 85”
Display Area (mm) 1872(H)*1053(V)
Brightness 2000 cd/m²
Resolution 3840 x 2160
Aspect Ratio 16:9
Contrast Ratio 400:1
Pixel Pitch (mm) 0.4875(H) x 0.4875(V)
Pixel Pre Inch (PPI) 52
Viewing Angle 178°(H),178°(V)
Color Saturation (NTSC) 90%
Display Colors 1.07 G
Response Time (Typical) 9.5ms
Video interface SDM-S, SDM-L
SDM Slot SDM-S/SDM-L
Input Power AC100~240V
Power Consumption 60W (Panel Model Only)
Dimensions (mm) 890x 890 x 75.7
Bezel Size(U/B/L/R) 15/15/15/15 mm
Weight (Net) 80kg
Mounting VESA 500x400, 500x600
OSD key 5 Keys (Power Switch, Menu, +, Exit, -)
OSD control Brightness, Color, Contrast, Auto Turing, H/V Position…etc
Operating Temperature 0 ˚C ~ 50 ˚C
Storage Temperature -20 ˚C ~ 60 ˚C
