Home / Product / AIoT Solution / AI Edge Computing / Intel® AI Solutions / IBOX-MTL0

Intel® AI Solutions

IBOX-MTL0

Intel® Core™ Ultra 7 / Ultra 5 Series SoC based 3.5" Embedded Board with 2 HDMI / 2 USB-C (with DP) / LVDS, SATA III, 2 COM, 2 UART, 8 USB, 2 LAN
▪ Intel® Meteor Lake -U/H & Arrow Lake -U/H Core™ Ultra series
SoC on board
▪ One 262-pin SO-DIMM up to 48GB DDR5 6400MT/s SDRAM
▪ Multi-Display : 2 HDMI / LVDS / 2 USB-C (DP interface)
▪ Two Intel® 2.5 Gigabit Ethernet ports
▪ 2xRJ45,2xUSB3.1,2xUSB2.0,2COM,1DIO
▪ Supports 4K/2K Resolution Display
▪ DC-IN 12V ~ 24V

PRINT
INQUIRY COMPARE

Main Features

  • M.2

  • 4K

INTRODUCTION SPECIFICATION Download
The IBOX-MTL0 is a high-performance, fanless industrial edge AI computer engineered for smart factories, machine vision, and multi-display control rooms. Powered by 14th Gen Intel® Core™ Ultra processors with integrated CPU, GPU, and NPU engines, it delivers up to 34 TOPS of heterogeneous AI computing power. It supports up to 96GB DDR5 memory, four-display output (2x HDMI + 2x Type-C), and offers versatile industrial connectivity including dual 2.5G LAN, multiple USB/COM/DIO ports, and three M.2 expansion slots. Housed in a compact, fanless chassis supporting 12V–24V wide DC input and 5–125W flexible thermal range, it features hardware TPM security and meets RoHS standards for reliable, energy-efficient ESG deployments.
Model name IBOX-MTL0
System
CPU Intel® Core™ Ultra 100H/U and 200H/U processor series on board, Core™ Ultra 7 155H (1.4GHz/4.8GHz, 6P+8E, 128EU, 28Wbase), Core™ Ultra 5 125H (1.2GHz/4.5GHz, 4P+8E, 112EU, 28Wbase), Core™ Ultra 7 155U (1.7GHz/4.8GHz, 2P+8E, 64EU, 15Wbase), Core™ Ultra 5 1
System memory DDR5 SDRAM up to 6400 MT/s
I/O
USB 2 x USB 3.2 Type-A (rear I/O), 2 x USB 3.2 Type-C (rear I/O), 2 x USB 2.0
COM 2 x RS-232/422/485 DIO 1 x 8-bit Programmabl
Display 2 x HDMI v1.4b, 2 x USB-C (with DP v2.1 interface)
Audio Line-out, Mic-in
Power
Power supply DC-IN 12V ~ 24V
Environmental
Operating Temperature 0°C ~ 60°C ( 32°F ~ 140°F)
Storage Temperature -40°C ~ 80°C (-40°F ~ 176°F)
Relative Humidity Operating: 5 to 95% RH, Storage: 5 to 95% RH
Mechanical
Weight 1.5 kg
Dimensions 180mm x 180mm x55.8mm

Download
