Performance BOX PC

IBOX-V1K0

Embedded Box System with AMD® Ryzen™ Embedded V1605 Processor
  • ▪ AMD® Ryzen™ Embedded V1000 APU on board
  • ▪ High Performance "Zen" Core CPU + "VEGA" Graphics GPU
  • ▪ Four [email protected] monitors support
  • ▪ Multi-Display: 4 x HDMI
  • ▪ 2 x LAN, 2 x USB 3.1
  • ▪ 1 x SATA III, 1 x Mini-PCIe(w/uSIM), 1 x M.2 M-key 2260(SSD)
  • ▪ DC-in 12V

Main Features

  • Quad Display

  • M.2

  • AI

IBOX-V1K0/V1K1 series, compact box computer, powered by AMD® Ryzen™ Embedded V1000 Soc, a breed of embedded board and box PCs can power up to four independent display in 4K and provide uncompromising performance, versatility and sophisticated automation capabilities across a wide range of applications.

IBOX-V1K0/V1K1 uses up to 32GB of dual channel DDR4 3200 MT/s memory (both ECC and non-ECC) with higher memory bandwidth for better performance and efficiency. The new integrated AMD Radeon™ Vega graphics with up to 11 compute units marks the cutting edge of embedded graphics. It supports up to four independent displays with up to 4K UHD resolution and 10-bit HDR, as well as DirectX 12 and OpenGL 4.4 for 3D graphics. The integrated video engine enables hardware-accelerated streaming of HEVC (H.265) video in both directions.

IBOX-V1K0/V1K1 adopts 10/100/1000 Mbps speeds Ethernet controller and flexible I/O interface options with: 1 x Mini-PCIe (full size), 1 x M.2 M Key, 1 x SATA Gen. 3 @ 6.0Gb/s, 2 x USB 3.1, 3 x USB 2.0, 3 x COM ports, watchdog timer, and GPIO to fulfill a wide variety of functions and high-performance system extension requirements.
Model name IBOX-V1K0
System
CPU AMD® Ryzen™ Embedded V1000 series APU
V1605 (2.0GHz, QC, 12-25W)
Chipset AMD® Ryzen ™ Embedded V1000 series APU integrated
BIOS AMI UEFI Flash ROM
System memory 2 x 260-pin DDR4 SDRAM max. up to 32GB
Graphic AMD® VEGA graphics up to 11CU
Watchdog timer Yes
I/O
USB 2 x USB 3.1, 3 x USB 2.0
COM 3 x COM (2 x RS-232, 1 x RS-232/422/485)
LAN 2
Display 4 x HDMI
Audio Mic-in, Line-out
PS/2 N/A
Others 2 x SMA hole
Storage Support
HDD 1 x 2.5" HDD
M.2 1 x M.2 M-key 2260
mSATA N/A
Expansion
Mini-PCIe 1 (Full-size w/ Mico-SIM)
M.2 N/A
Power
Power supply DC 12V input
Environmental
Operating Temperature 0°C ~ 40°C
Storage Temperature -20°C ~ 60°C
Relative Humidity 0% ~ 90% (non-condensing)
Mechanical
Construction Metal
Standard color Grey
Mounting Desktop
Weight 1.77 kg
Dimensions (W)x(D)x(H)mm 206.4mm(W) x 188.5mm(D) x 48.9mm(H)
