Écran de signalisation numérique

2705-I

27” TFT LCD, 500 nits LED Backlight, 1920x1080
  • High Brightness 1000 nits
  • Sunlight Readable
  • LED Backlight
  • Low Power Consumption
  • BL MTBF: 50,000 hours
IMPRIMER
DEMANDE COMPARER

Principales caractéristiques

  • Low Power Consumption

INTRODUCTION Spécifications TÉLÉCHARGER
The 2705-I is a 27 inch industrial grade sunlight readable LCD, with high brightness 1000 nits, it produce sharp images, crisp text and lifelike colors. The Ubipixel LED backlight technology ensures high reliability and low power consumption, suitable for outdoor application, kiosk, factory automation, military, transportation and gaming application.
Model Name ULF2705-I ULH2705-I ULO2705-I ULO2705-IHT
Description 27” TFT LCD, 1000 nits LED Backlight, 1920x1080 27
” TFT LCD, 1000 nits LED Backlight, 1920x1080 Projected Capacitive Touch
size 27”
Display area (mm) 597.888 (H) x 336.312 (V)
Brightness 1000 cd/m²
Resolution 1920x1080
Aspect ratio 16:9
Contrast ratio 1400 : 1
Pixel pitch (mm) 0.3114 (H) x 0.3114 (V)
Pixel per inch (PPI) 82
Viewing angle 176° (H), 176° (V)
Color saturation (NTSC) 84% 69%
Display colors 16.7M
Response time (Typical) 14ms
Panel Interface LVDS
Input Interface HDMI,DP
Touch Interface   USB
Input power DC 12V
Power consumption 24W 27W
Dimensions (mm) 630.0 x 368.2 x 22.81 632.6 x 370.8 x 48.8 649 x 387.5 x 53
Bezel size (U/B/L/R) 15.944/15.944/16.056/16.056 mm 17.2/17.2/17.4/17.4 mm 25.6/25.6/25.6/25.6 mm
Weight (Net) 3.5Kg 7.18Kg 9.1Kg
Mounting   100 x 100 mm, 300 x 200 mm
OSD key 4 Keys (Power Switch, Menu, +, -)
OSD control Brightness, Color, Contrast, Auto Turing, H/V Position…etc
Operating temperature 0 ˚C ~ 50 ˚C
Storage temperature -20°C ~ 60°C
