Transportation Panel PCs
IPPS-4805-APL9
48" Bar-type Panel PC with Intel® Apollo Lake Atom® SoC
- Intel@ Apollo Lake Atom@ SoC
- EN50155
- 48" LCD, 1920 x 268, 1000 nits
- High Brightness, Sunlight Readable
- Auto-Dimming
- 3mm Glass with Front IP65 Full Flat Design
- Display Thickness 25mm; 1.5mm Slim Border
- M12 Connector for LAN, DC 110V input
IPPS-4805-APL9 is a fanless Passenger Information System, serving as a reliable platform to provide passenger information on wide versatility of vehicles, such as trains and trams. It features extra slim and lightly design to fit in cramped space.
Powered by Intel® Atom®/Pentium®/Celeron® (ApolloLake SoC) Processor, and designed from the ground up to be robustness with Front IP (Ingress protection) 65 with full flat design. It supports sunlight readable with auto dimming for smoothly implementation in a wide working temperature ranging from -20°C to 50°C, to make sure its best operation in harsh environment and deliver the real-time information to passengers.
Powered by Intel® Atom®/Pentium®/Celeron® (ApolloLake SoC) Processor, and designed from the ground up to be robustness with Front IP (Ingress protection) 65 with full flat design. It supports sunlight readable with auto dimming for smoothly implementation in a wide working temperature ranging from -20°C to 50°C, to make sure its best operation in harsh environment and deliver the real-time information to passengers.
Model Name | IPPS-4805-APL9 |
LCD | |
Display Type | 48" Resizing TFT LCD |
Aspect Ratio | 1200:1 |
Resolution | 1920x268 pixel |
Brightness | 1000 cd/m² |
Color | 16.7M Colors |
Pixel Pitch (H/V) | 0.63 x 0.63mm |
Constrast Ratio | 1200:1 |
Viewing Angle (H/V) | 178°/178°(typ.) |
Backlight MTBF (typ.) | 100,000 hrs(typ.) |
System | |
Memory | 1 x DDR3L SDRAM;max. up to 8GB |
Graphic | Intel® HD Gen 9-LP Graphics |
Watchdog Timer | interval: Programmable 1-255 sec. Output:System reset |
Indicators | 1 x System indicator |
Controls | N/A |
System I/O | |
USB | 2 x LAN Connector Type:M12 Can add COM, USB Port |
Environment | |
Operating Temperature | 0°C-50°C |
Storage Temperature | -20°C-60°C |
