モジュール式パネルPC

IPPS-1902

19" IP65 P-CAP Panel PC
  • 19" LCD, 1280 x 1024 pixel
  • 10 points P-CAP touch screen
  • Front IP 65
  • True Flat Design
  • Fanless design
Mix and Match with
Entry BOX PC
Performance BOX PC

主な特長

  • Multi-touch

  • Front Panel IP65

  • Fanless

Model Name IPPS-1902
LCD
Display Type 19" SXGA TFT LCD
Display Area (mm) 376.3(H) x 301.1(V) mm
Aspect Ratio 5:4
Resolution 1280 x 1024
Brightness 350 cd/m²
Color 16.7M
Color saturation (NTSC) 80%
Pixel Pitch (H/V) 0.294mm x 0.294mm
Constrast Ratio 1000:1 (typ.)
Viewing Angle (H/V) 170°/160° (typ.)
Backlight MTBF (typ.) 50,000 hrs (typ.)
Touch Screen Type P-CAP 10 points
Power
LCD Power Consumption 20.55W
Environment
Operating Temperature 0°C ~ 50°C (-20°C optional)
Storage Temperature -20°C ~ 60°C
Relative humidity 0% ~ 90% (non-condensing)
IP level Front IP65
Mechanical
Construction Heavy-duty steel
Standard Color Silver or dark grey
Dimensions (W)x(D)x(H)mm 464.1mm(W) x 37.2mm(D) x 388.8mm(H)
Weight 5.5 kg
