Accueil / Produit / ITRP-0705-RKC4

Transportation Panel PCs

ITRP-0705-RKC4

7” TFT LCD, 500 nits LED Backlight, 1280x800
  • High Brightness 500 nits
  • EN50155 / EN45545
  • LED Backlight
  • Front IP65
  • 1x M12 POE、1x M12 RJ45
  • 3mm AR Glass PCAP (IK04)
  • Wide Temperature (-25 ˚C ~55 ˚C)
  • Low Power Consumption
IMPRIMER
DEMANDE COMPARER
INTRODUCTION Spécifications TÉLÉCHARGER
The ITRP-0705-RKC4-WP00-2001 is a 7-inch industrial-grade, sunlight-readable LCD with 500 nits of high brightness. It delivers sharp images, crisp text, and lifelike colors.
Equipped with Ubipixel LED backlight technology, it offers high reliability and low power consumption. This display is ideal for applications including outdoor environments, kiosks, factory automation, military systems, transportation, and gaming.
Model Name ITRP-0705-RKC4-WP00-2001
 Description 7" TFT LCD, 500 nits LED Backlight, 1280x800
Screen Size 7"
 Display Area (mm) 149.76(H) x 93.60(V)
 Brightness 500 cd/m2
 Resolution  1920x1080
 Aspect Ratio  16 : 10
Contrast Ratio  1000 : 1
 Pixel Pitch (mm) 0.117(H) x 0.117(V)
 Viewing Angle  178°(H),178°(V)
I/O Port 1x D-coded 4Pin Female RJ45, 1x X-coded 8pin Female RJ45
 CPU Rockchip RK3566Processor Quad-core Cortex-A55
 OS Debian 10
RAM 4GB LPDDR4 4GB
Storage eMMC 32GB
 Input Power POE input (802.3at)
 Glass 3mm AR Glass PCAP
Power Consumption 8W
 IP Level Front IP65
 Dimensions (mm) 180 x 152 x 43 mm
Weight (Net) 830g
 Operating Temperature -25 ˚C ~ 55 ˚C
 Storage Temperature  -25 ˚C ~ 55 ˚C
Certification EN50155、EN45545
