Home / Product / Industrial Display / Durapixel™ - Sunlight Readable LCDs / DPF5501-LNN

Digital Signage Display

DPF5501-LNN

55” TFT LCD, 4000 nits LED Backlight, 1920x1080
  • High Brightness 4000 nits
  • Sunlight Readable
  • Resolutions: 1920 x 1080
  • Wide Viewing Angle of 178°(H),178°(V)
  • LCD Blackening Defect Free (H-Tni 110 ˚C)
  • Low Power Consumption
  • BL MTBF: 100,000 hours
PRINT
INQUIRY COMPARE

Main Features

  • Wide Viewing Angle

  • Sunlight Readable

  • MTBF 100K

  • Low Power Consumption

  • Digital Signage

INTRODUCTION SPECIFICATION Download
The DPF5501-LNN is a 55 inch industrial grade sunlight readable LCD, with high brightness 4000 nits, it produces sharp images, crisp text and lifelike colors. The Durapixel LED backlight technology ensures high reliability and low power consumption, suitable for outdoor application, kiosk, factory automation, military, transportation and gaming application.
Model name DPF5501-LNN
Description 55” TFT LCD, 4000 nits LED Backlight, 1920x1080
Size 55”
Display Area (mm) 1209.6(H) x 680.4(V)
Brightness 4000 cd/m2
Resolution 1920x1080
Aspect Ratio 16 : 9
Contrast Ratio 1600 : 1
Pixel Pitch (mm) 0.630(H) x 0.630(V)
Pixel Per Inch (PPI) 40
Viewing Angle 178°(H),178°(V)
Color Saturation (NTSC) 80%
Display Colors 16.7M
Response Time (Typical) 9ms
Operating Temperature 0 ˚C ~ 50 ˚C
Storage Temperature -20 ˚C ~ 60 ˚C
