Modular Panel PCs & Monitors

IPPC-1583-RKC3

15.8” TFT LCD, LED Backlight 500 nits, FHD (2560x600)
▪ Brightness 500 nits
▪ Quad-core ARM Cortex-A55 CPU and
  Mali-G52 GPU
▪ 2GB RAM, 16GB eMMc flash
▪ 3mm Tempered Glass
▪ Full IP54
▪ Android
PRINT
INQUIRY COMPARE

Main Features

  • Wide Temp

  • Wide Viewing Angle

  • Transportation

  • Sunlight Readable

  • Low Power Consumption

  • IP54

  • Digital Signage

INTRODUCTION SPECIFICATION Download
The IPPC-1583-RKC3 is a 15.8-inch industrial-grade, sunlight-readable LCD with a brightness of 500 nits and high color saturation. It delivers sharp images, crisp text, and lifelike colors.
Equipped with Durapixel LED backlight technology, it ensures high reliability and low power consumption. This display is well-suited for applications such as outdoor environments, kiosks, factory automation, and gaming.
Model Name IPPD-1583-RKC3
Description 15.8" TFT LCD, 500 nits LED Backlight, 2560x600
size 15.8"
Display area (mm) 92.85(H) x 391.26(V)
Brightness 500 cd/m2
Resolution 2560 x 600
Aspect ratio Bar Type
Contrast ratio 1000 : 1
Pixel pitch (mm) 152.25(H) ×152.25(V)
Viewing angle 178° (H), 178° (V)
Glass 53mm Tempered Glass
IP Level Full IP54
CPU Rockchip RK3566 Quad-core ARM Cortex-A55 CPU
RAM 2GB LPDDR4
Storage 16GB eMMC
Interface  USB2.0x2、Power(Terminal)x1
OS Android 11.0
Power input AC 110 -240 V
Power Consumption 20W
Dimensions (mm) 440 x 130 x 61 mm
Weight (Net) 2.3 KG
Operating Temperature 0˚C ~ 60 ˚C
Storage Temperature -25˚C ~ 75 ˚C

Download
